Mersen Surge Protector Type 2+3 SPD 4 Pole 230/400 Volt 10KA TNS Remote Indication

Available at LED Controls the Mersen Type 1 surge protector STPT23-20K275V-4P-LFM has 4 poles and operates at 230/400 volts. The maximum continuous operating voltage is at 275 volts with a nominal discharge current of 10ka. The peak current can be withstood 20 times before the unit reaches end of life. These cartridges are replaceable.

This surge arrestor is din rail mountable and the live, neutral and earth contacts are clearly marked. A small phillips screwdriver is used to tighten or loosen the contacts.

Surge protection devices divert excess current to earth which prevents damage to electrical wiring and electrical shock in an over voltage event. These are also known as SPD’s. This surge protector has remote indication.
